SBT - Stainless Steel Braided Smooth Bore PTFE Teflon® Lined Hose
- Unpigmented, smooth bore Teflon® PTFE liner
- 316 Stainless steel reinforcing braid
Benefits:
- Full vacuum, low cost smooth bore
- Longer length availability
- "True ID" provides full flow characteristics and simple dimensional match to flow specifications
- Easy to clean
Applications:
- Laminar flow, economy hose
Connections:
- Flanged
- Cam and Groove
- Sanitary
- NPT
| Nominal Size | ID | OD | Bend Radius | Working Pressure @ 70°;F | Burst Pressure @ 70°;F | Natural Part Number | Conductive Part Number | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | DN | Inch | MM | Inch | MM | Inch | MM | PSI | BAR | PSI | BAR | ||
| 1/2 | 15 | 0.500 | 12.7 | 0.633 | 16.1 | 6.5 | 165.1 | 1425 | 98.2 | 5700 | 393.0 | 08-SBT-W | 08-SBT-B |
| 3/4 | 20 | 0.750 | 19.1 | 0.875 | 22.2 | 8.2 | 208.3 | 1000 | 68.9 | 4000 | 275.8 | 12-SBT-W | 12-SBT-B |
| 1 | 25 | 1.000 | 25.4 | 1.190 | 30.2 | 12 | 304.8 | 1000 | 68.9 | 4000 | 275.8 | 16-SBT-W | 16-SBT-B |
| 1-1/2 | 40 | 1.500 | 38.1 | 1.762 | 44.8 | 14 | 355.6 | 1000 | 68.9 | 4000 | 275.8 | 24-SBT-W | 24-SBT-B |
NOTE: In an assembly, the pressure ratings of fittings may be less than hose pressure ratings.
